The Domopac domestic cold water booster set with integral break tank is designed for use in domestic and commercial applications where the existing mains supply is inadequate.

Features

Increased Water Pressure & Flow

The Domopac range can increase water pressure & flow to meet demands in domestic, commercial, agricultural and industrial applications.

Compact design

The typical areas for installation of the Domopac range are garages, plant rooms, utility rooms and kitchens.

Quiet & reliable

Incorporating an ultra-quiet running submersible pump within a tank unit makes this range of products quiet and reliable.

Easy to install

The Domopac range are all-in-one tank and pump units designed to be fast and easy to install. See our Download section for more information.

Dry run protection

The Domopac range has dry run protection with auto restart (time delay).

Marked Product

Domopac products are CE marked, meaning they comply with EU safety, health and environmental requirements.

Models

Domopac Compact

Fitting into the space of a standard kitchen unit the Domopac Compact is a similar size to a washing machine so can be hidden away behind a cupboard door. The electronic controller automatically starts and stops the pump when a drop in pressure is sensed (i.e. a tap is opened and closed).

Domopac Slimline

The Domopac Slimline can fit through a standard doorway. This makes it very convenient for new or existing properties as it can be easily fitted under stairs, in a garage or in a utility room. The Domopac Slimline is ideal for 3-5 bedroom houses, with poor water pressure and flow and where floor space is limited.

Domopac Utility 500ltr & 750ltr

The Domopac Utility 500ltr & 750ltr is designed for domestic and light commercial use where there is low mains water pressure and where pressure fluctuates. It is electronically controlled through a flow switch unit which starts and stops the pump automatically when a tap is opened and closed.

Domopac Utility 650ltr & 1000ltr

The Domopac Utility 650ltr & 1000ltr is designed for commercial use on a larger scale where there is low mains water pressure and where pressure fluctuates. It is electronically controlled through a flow switch unit which starts and stops the pump automatically when a tap is opened and closed.

Domopac Rectangular 270ltr

The Domopac Rectangular 270ltr is designed for houses and apartments where there is low mains water pressure and where pressure fluctuates. It is electronically controlled through a flow switch unit which starts and stops the pump automatically when a tap is opened and closed.

Domopac Rectangular 300ltr & 500ltr

The Domopac Rectangular 300ltr & 500ltr are designed for domestic and light commercial use where there is low mains water pressure and where pressure fluctuates. It is electronically controlled through a flow switch unit which starts and stops the pump automatically when a tap is opened and closed.

Domopac Bunded

Every Domopac Bunded tank benefits from a ‘tank within a tank’ bunded construction, with the outer tank able to maintain a minimum of 110% of the volume of the inner tank. The inner tank acts as the primary storage container, whilst the outer tank acts as a fail-safe in the event of a spill.

Domopac Skinny

With 57L and 100L tank options, these are suited to smaller properties like 2 bedroom townhouses or flats and apartments. The Domopac Skinny house booster units are designed as a ‘plug and play’ style answer to boosting your water pressure and flow, giving you back your shower.

Domopac CAT 5

The Domopac CAT 5 provides backflow protection for fluid category 5 risks. The system includes a type AB airgap and has a water volume of 10 ltrs. We supply this tank with a self-priming jet pump to ensure smooth operation.

Components

Top Multi II

• Flow rate up to 80ltr/min

• Head pressure up to 4.2 bar

• Max liquid temperature 40°C

• Power consumption 0.55kW

Top Multi-Tech (Auto)

• Flow rate up to 80ltr/min

• Head pressure up to 4.2 bar

• Built-in electronic start/stop

• Dry running protection

• Power consumption 0.55kW

Presflo Multi

• LCD display unit

• Adjustable cut-in-feature

• 3ltr surge tank

• Dry running protection with auto restart

• Resin bonded electronics

Presflo

• LCD display unit

• 1.5 bar cut-in pressure

• Dry runnign protection with auto restart

• Resin bonded electronics

SteadyPres

• LCD display unit

• Energy efficient

• Dry running protection

• Excessively frequent starts

• Overcurrent protection

Slimline Drip Tray

• Suitable for 200/300ltr Slimline range

• 1" overflow connection

• Lift handles

NKM 2/2 Pump

• Flow rate up to 80ltr/min

• Head pressure up to 4.6 bar

• Power consumption 0.55kW

NKM 2/3 Pump

• Flow rate up to 80ltr/min

• Head pressure up to 6 bar

• Power consumption 0.75kW

Pressure Vessel

• Stainless steel nipple 1”

• 10 bar working pressure

• WRAS approved product

Connection Kit for Compact

• 1m flexible inlet hose, 15mm Aquavend, Speedfit connection

• 600mm flexible outlet hose, 22mm Aquavend, Speedfit connection

• HEPVO 40mm CVI self sealing trap with CV3 adaptor McAlpine Flexcon 2 450mm flexible waste pipe 90° elbow 40mm, 100mm x 40mm waste pipe

Wall Bracket Support

• Adjustable arm length

• 1” connection

UV Filtration

• Flow rate up to 70ltr/min at 30mJ/cm²

• Ultra violet disinfection

• Includes 5 micron pre-filtration

• 1" Connections

• 60 WATT

Tanks

Compact

125ltr tank only

Slimline

200ltr tank only

300ltr tank only

Utility

500ltr tank only

650ltr tank only

750ltr tank only

1000ltr tank only

Rectangular

270ltr tank only

300ltr tank only

500ltr tank only
